Rockwell Automation Publication 193-UM002I-EN-P - December 2011 139
Monitoring Parameters Chapter 6
L2 %FLA
This parameter provides the L2 phase
current
measurement as a percentage of the
motor’s full load current rating (Parameter
28, FLA Setting).
Parameter Number 6
Access Rule Get
Data Type UINT
Object Mapping 2C
hex
-1-106
Group Monitor
Units % FLA
Minimum Value 0
Maximum Value 1000
Default Value None
L3 %FLA
This parameter provides the L3 phase
current measurement as a percentage of
the motor’s full load current rating
(Parameter 28, FLA Setting).
Parameter Number 7
Access Rule Get
Data Type UINT
Object Mapping 2C
hex
-1-107
Group Monitor
Units % FLA
Minimum Value 0
Maximum Value 1000
Default Value None
AVERAGE %FLA
This parameter provides the average
current measurement as a percentage of
the motor’s full load current rating
(Parameter 28, FLA Setting).
Parameter Number 8
Access Rule Get
Data Type UINT
Object Mapping 2C
hex
-1-108
Group Monitor
Units % FLA
Minimum Value 0
Maximum Value 1000
Default Value None
% THERM UTILIZED
This parameter reports the calculated
percent thermal capacity utilization of the
connected motor.
Parameter Number 9
Access Rule Get
Data Type USINT
Object Mapping 2C
hex
-1-109
Group Monitor
Units %
Minimum Value 0
Maximum Value 100
Default Value None
GF CURRENT (E3 Plus)
This parameter provides the ground fault
current measurement in amperes.
Parameter Number 10
Access Rule Get
Data Type INT
Object Mapping 2C
hex
-1-110
Group Monitor
Units Amps
Minimum Value 0.00
Maximum Value 12.75 (approx.)
Default Value None
