Appendix B DeviceNet™ Information
Table 101 - Connection Object Instance 1 Attributes
The following Instance 2 (polled I/O connection) attributes are supported.
Table 102 - Connection Object Instance 2 Attributes
Attribute
ID
Access
Rule
Name
Data
Type
Value
1
Get
State
USINT
0 = Nonexistent
1 = Configuring
3 = Established
4 = Timed out
2
Get
Instance Type
USINT
0 = Explicit message
3
Get
Transport Class Trigger
BYTE
0x83 (Class 3 Server)
4
Get
Produced
Connection ID
UINT
10xxxxxx011
xxxxxx = Node address
5
Get
Consumed
Connection ID
UINT
10xxxxxx100
xxxxxx = Node address
6
Get
Initial Comm Characteristics BYTE
0x22
7
Get
Produced Connection Size
UINT
0x61
8
Get
Consumed Connection Size
UINT
0x61
9
Get/Set
Expected Packet Rate
UINT
in ms
12
Get/Set
Watchdog Action
USINT
1 = Auto delete
3 = Deferred delete
13
Get
Produced Connection
Path Length
UINT
0
14
Get
Produced Connection Path
Null (no data)
15
Get
Consumed Connection
Path Length
UINT
0
16
Get
Consumed Connection Path
Null (no data)
Attribute
ID
Access
Rule
Name
Data
Type
Value
1
Get
State
USINT 0 = Nonexistent
1 = Configuring
3 = Established
4 = Timed out
2
Get
Instance Type
USINT 1 = I/O Message
3
Get
Transport Class
Trigger
BYTE
If alloc choice = polled
OR
If alloc choice = !polled && !ack suppressed:
0x82 (Server Class 2)
If alloc choice = !polled && ack
suppressed:
0x80 (Server Class 0)
4
Get
Produced
Connection ID
UINT
01111xxxxxx
xxxxxx = Node address
5
Get
Consumed
Connection ID
UINT
10xxxxxx101
xxxxxx = Node address
