Rockwell Automation Publication 193-UM002I-EN-P - December 2011 261
DeviceNet™ Information Appendix B
MCC Object - CLASS CODE
0x00C2 A single instance (instance 1) of the MCC Object will be supported:
The following common services will be implemented for the MCC Object:
Logic Supervisor Object -
CLASS CODE 0x030E A single instance (instance 1) will be supported. The following instance
attributes will be supported.
Table 130 - MCC Object Instance Attributes
Attribute ID Access
Rule Name Data
Type Range Value
1 Get/Set Mcc Number USINT 0…255 0
2 Get/Set
Vertical Section
Number
USINT 0…255 0
5 Get/Set Strarting Section Letter USINT 0…255 65
6 Get/Set Space Factors USINT 0…255 0x3F
7 Get/Set Cabinet Width USINT 0…255 0
8 Get/Set Mcc Number USINT 0…255 0
9 Get
Number of Device
Inputs
USINT
EC1=2
EC2=EC3=EC4=4
EC5=6
10 Get/Set
Devices Connected at
Inputs Array of
USINT
00000000000000
Table 131 - MCC Object Common Services
Service
Code Implemented for: Service
Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
0x18 No Yes Get_Member
0x19 No Yes Set_Member
Table 132 - Logic Supervisor Object Instance Attributes
Attribute ID Access
Rule Name Data Type Range Value
1 Get/Set Logic Enable BOOL
0=Logic
Disabled
1=Logic
Enabled
0
2 Get Data Table
Array of
BYTE The Standard
Bit Table
0
5 Get Last Error UDINT
Last error
code
65
6 Get
FB Classes
Implemented
STRUCT of:
USINT
Array of
UINT
4
775, 776,
777, 778
0x3F
