Rockwell Automation Publication 193-UM002I-EN-P - December 2011 153
Voltage Parameters Chapter 7
UV Trip Level
This parameter sets the under voltage trip
level. Parameter Number 217
Access Rule Get/Set
Data Type UINT
Object Mapping 0Fhex-D9-01
Group Voltage Setup
Units Volts
Minimum Value 0
Maximum Value 65535
Default Value 100
UV Warn Level
This parameter sets the under voltage
warning level.
Parameter Number 218
Access Rule Get/Set
Data Type UINT
Object Mapping 0Fhex-DA-01
Group Voltage Setup
Units Volts
Minimum Value 0
Maximum Value 65535
Default Value 400
OV Inhibit Time
This parameter defines the amount of time
for which an over voltage detection is
inhibited during a motor starting
sequence. Parameter Number 219
Access Rule Get/Set
Data Type USINT
Object Mapping 0Fhex-DB-01
Group Voltage Setup
Units Seconds
Minimum Value 0
Maximum Value 250
Default Value 10
OV Trip Delay
This parameter allows the installer to
program a time duration for which an over
voltage condition must exist prior to the
device tripping.
Parameter Number 220
Access Rule Get/Set
Data Type USINT
Object Mapping 0Fhex-DC-01
Group Voltage Setup
Units Seconds
Minimum Value 0.1
Maximum Value 25.0
Default Value 1.0
OV Trip Level
This parameter sets the over voltage trip
level.
Parameter Number 221
Access Rule Get/Set
Data Type UINT
Object Mapping 0Fhex-DD-01
Group Voltage Setup
Units Volts
Minimum Value 0
Maximum Value 65535
Default Value 500
