Feature implementation 569
The following packages are also required:
• Japan Central Office Trunk (JPN) package 97
• Intelligent Peripheral Equipment (XPE) package 203
Feature implementation
Task summary list
The following is a summary of the tasks in this section:
1. LD 97 – Assign Tone Characteristics to Busy Tone Detection Tables.
2. LD 14 – Assign Busy Tone Detection to Central Office (CO), Foreign
Exchange (FEX) and WATS Trunks.
3. LD 14 – Assign Busy Tone Detection to Direct Inward Dialing (DID)
Trunks.
LD 97 - Assign Tone Characteristics to Busy Tone Detection Tables.
Prompt Response Description
REQ CHG Change existing data.
TYPE BTD Busy Tone Detection data block.
BTDT (0)-7
X1-X7 Busy Tone Detection table.
Table 0 can be changed but cannot be removed. Table 0
should always exist (when the BTD package is equipped) and
is initialized to the default value for Japan. When creating
alternate tables, table 0’s values are used to fill the table and
these can be changed. Enter X in front of the table number to
remove the table.
BCAD 500 500
(ph1 ph2) Busy Tone Cadence (on and off phase length during the cycle
can be entered). ph1 is the ON cycle and ph2 is the OFF cycle.
The values for each phase can be 0 to 1.5 seconds (1500 ms)
and are entered as ms. The input values are rounded to the
nearest multiple of 25 ms. Entering all 0s indicates continuous
tone. A tone is deemed continuous if it lasts for at least 3.2
seconds. The smallest cadence is 50 ms even though 25 ms
can be entered.
BTDD (BOTH) Busy Tone Detection Direction.
BOTH = both incoming and outgoing calls
INC INC = incoming calls only
LD 14 - Assign Busy Tone Detection to Central Office (CO), Foreign Exchange (FEX) and
WATS Trunks.
Prompt Response Description
REQ NEW
CHG Add new data.
Change existing data.
