Connection information for expansion units
The connection status (connected or unconnected) of a connected expansion unit
can be confirmed using the Access Window, the ladder support software "KV
IncrediWare (DOS)" and "LADDER BUILDER for KV", or the KV-P3E(01) handheld
programmer.
➮ Refer to "Chapter 3. Access Window" (p.1-79), "Chapter 6. Handheld Programmer" (p.1-195), and the
"6.2.9. Displaying the Use Status" (p. 2-70).
The connection information is written to data memory DM1937 as shown in the table
below.
*
Always set to "0" when the KV-40xx is used.
In the case of connection above, DM1937 is set as follows.
