6.3 Functions
Chapter 6 Handheld Programmer
1-216
6
A L L C L E A R
F N C [ 6 0 ] F N C [ 6 1 ]
P 3 E C L E A R
OFF
ON
6.3 Functions
Function Nos. list
The KV has 16 functions for quick and easy programming or trial run.
A function No. [FNCxx] is assigned to each function. The functions are set using
[FNC] in the same way as entering the basic instructions, application instructions,
arithmetic instructions, or interrupt instructions.
Function Nos. list
MODE:
P: PROGRAM mode
R: RUN mode (OFFLINE EDITOR not used)
E: OFFLINE EDITOR in use
■ To find function No. assigned to desired function:
Press [FNC], and the cursor appears at the position where the function No. is to be
entered. Pressing
ON
or
OFF
scrolls the functions and assigned Nos., making it
easy to find the desired function No.
Example
Function Function No. Mode Reference
page
[ALL CLEAR] 60 P 1-217
[P3E CLEAR] 61 P E 1-217
Handheld programmer Clear
[CTR CLEAR] 62 P 1-218
Counter Clear
[HIGH-SPEED CTR CLR] 63 P 1-218
High-Speed Counter Clear
[DM ALL CLEAR] 64 P 1-219
All Data Memory Clear
[L-RELAY ALL RST] 65 P 1-219
All Latching Relays Reset
[COMMUNICATION —] 66 P E 1-220
Program Sent or Received
[OFFLINE EDITOR] 67 R 1-221
Offline Editor Start
[QUIT OFF-L EDIT] 68 E 1-221
Offline Editor Stop
[CHG: T/C CURT-V] 69 P R 1-222
Timer/counter Current Value Change
[CHG: T/C SET-V] 70 PR 1-224
Timer/counter Setting Change
[FORCED SET/RESET] 71 PR 1-226
Relay On/Off
[DM WRITE] 72 PR 1-227
Write Into Data Memory
[TRIMMER MONITOR] 73 PRE 1-228
Read Trimmer Setting
[PROGRAM CHECK] 74 PE 1-228
Syntax Check
[PROGRAM SIZE] 75 PE 1-229
Program Capacity Check
