7.10 Command List KV-300 Series Only
KV
-300
KV-10/80
Chapter 7 KV-L2 Serial Interface Module
1-309
1
7
7.10.2 List of Commands and Responses in Display
Interface mode
Format of command and response
FCS @ ❋ C
R Station no.
Header
code
Command/response
Range of station no.: 00 to 15
Command Response
Header Function Header Command data Header Response
code code code data
RR Read I/O relay/internal utility relay RR Read start ch. RR End code
Number of channels Data read
to read
RH Read temporary memory/analog timer RH Read start no. RH End code
Number of timers Data read
to read
RC Read current value of counter/timer/high-speed RC Read start no. RC End code
counter Number of counters/ Data read
timers to read
RG Read status of counter/timer/high-speed counter RG Read start no. RG End code
comparator Number of counter/ ON/OFF
timer/comparator to information
read
RD Read DM RD Read start DM no. RD End code
Number of DM Data read
addresses to read
RJ Read I/O relay/internal utility relay RJ Read start ch. RJ End code
Number of channels Data read
to read
WR Forced update of I/O relay/internal utility relay WR Write start ch. WR End code
Data to write
WH Update temporary memory WH Write start ch. WH End code
Data to write
WC Update current value of counter/timer/high-speed WC Write start no. WC End code
counter Data to write
WG Forced update of status of counter/timer/high- WG Write start no. WG End code
speed counter comparator Data to write
WD Update DM value WD Write start no. WD End code
Data to write
WJ Forced update of I/O relay/internal utility relay WJ Write start ch. WJ End code
Data to write
R# Read set value of counter/timer/high-speed R# Instruction word R# End code
counter comparator Operand Set value
W# Update set value of counter/timer/high-speed W# Instruction word
counter comparator Operand
New set value
W# End code
MS Read KV-300 CPU operation mode MS MS End code
Operation
mode
SC Change KV-300 CPU operation mode SC Operation mode SC End code
KS Set KS Device Changed no. KS End code
Changed bit
KR Reset KR Device KR End code
No. to change
Bit to change
