1.4 KV-10AR/AT(P)/DR/DT(P) (10-I/O Basic Unit)
■ Output circuit diagram
503 500
502
R502
501
C3
*
0V 24V
500 to 503
C3
R502
1.6kΩ W 1 2
Internal circuit
Insulating
power
supply
Internal
circuit
• 1.6 kΩ current limiting resistor is built in R502
(to connect a motor driver).
L
AC100V-240V 0.4A
50/60Hz
FG
N
L N ~
* For KV-10ATP/DTP
PNP NPN
1.4.3 AC Power Input (KV-10AR/AT(P))
Insultating
power
supply
Internal circuit
500 to 503
C3
R502
1.6 kΩ W 1 2
• 1.6 kΩ current limiting resistor is built in R502
(to connect a motor driver).
