6.3 Functions
Chapter 6 Handheld Programmer
1-221
1 6
OFFLINE EDITOR START RUN mode
(OFFLINE EDITOR) [FNC67]
Function
• Edits program using handheld programmer while KV is in operation.
• The program can be edited by following the same procedure as in the PRO-
GRAM mode. (The accessible functions, however, are restricted.)
• This function is used to edit the program for the memory card while the KV is in
use. Accordingly, when OFFLINE EDITOR is quitted [FNC68], the program is not
written into the KV, but the program in the KV is read onto the programmer.
• When stopping the operation of the KV while OFFLINE EDITOR is in use, change
the mode switch to PROGRAM. You can enter the PROGRAM mode without
clearing the program on the handheld programmer.
Note: To write the edited program into the KV, use the PROGRAM SENT OR
RECEIVED function [FNC66] and then quit the OFFLINE EDITOR function. In this
case, the KV stops the operation to write the new program, and then starts the
operation from the top of the program. Note that the timer values will be reset.
Key operation
Basic operation
Example of operation
OFFLINE EDITOR STOP OFFLINE EDITOR
(QUIT OFF-L EDIT) [FNC68]
Function
Quits OFFLINE EDITOR.
When quitting the OFFLINE EDITOR function, the program is automatically verified
with that in the KV PLC. If two programs do not match, the program in the PLC is
read onto the programmer. If changes have already been made on the program in
the PLC, this program is automatically read onto the programmer.
Key operation
Basic operation
Example of operation
ORB
6
LD
7
ENT
R-SRCH FNC
Key operation Display Description
RUN
Initial display (RUN mode)
FNC[67] Access OFFLINE EDITOR START
OFFLINE EDITOR [OFFLINE EDITOR] function.
00000
Line 0 is displayed.
LD 00000
FNC
ENT
R-SRCH
Key operation Display Description
00000
Display arbitrary line.
LD 00000
READ/LOAD OK When program differs from that in
PUSH CLR TO CONT KV PLC the latter is read.
RUN Return to initial display of RUN
mode.
FNC
ENT
R-SRCH
ORB
6
CLEAR
ORB
6
AND
8
ENT
R-SRCH FNC
AND
8
