5.3 Module/Unit Connections
KV
-300
KV-10/80
1
5
Chapter 5 KV-300 Hardware
1-185
KV-C32T/B16R/B16S
Pin No. Signal
1 500
2 501
3 502
4 503
5 504
6 505
7 506
8 507
9 508
10 509
11 510
12 511
13 512
14 513
15 514
16 515
17 COM
18 600
19 601
20 602
21 603
22 604
23 605
24 606
25 607
26 608
27 609
28 610
29 611
30 612
31 613
32 614
33 615
34 COM
DC
DC
Note: Pins 17 and 34 of the
KV-C32T are connected
internally.
➮ For instructions on crimping
connectors to cables, refer
to p.1-189.
1 18
17 34
Connector Pin
assignment
1 18
2 19
3 20
4 21
5 22
6 23
7 24
8 25
9 26
10 27
11 28
12 29
13 30
14 31
15 32
16 33
17 34
Signal
500
501
502
503
504
505
506
507
COM1
508
509
510
511
512
513
514
515
COM2
DC or AC
power
supply
DC or AC
power supply
Signal
500
501
502
503
504
505
506
507
COM1
508
509
510
511
512
513
514
515
COM2
AC
AC
➮ For directions on removing
the terminal block, refer to
page 1-181.
Terminal block Nos.
500
503
504
506
COM1
509
511
513
151
501
503
505
507
508
510
512
514
COM2
