3.4 Device Mode

Chapter 3 Access Window

1-88

Visual KV

Series

Selecting the device and displaying the current value/set value

Select the device type and the device No. to be displayed.

■ Operating procedure
1. Select the device type.

Select the device type using the

key. Each time the

key is pressed, the

device type is changed among DM, TM, T/C, CTC, TRM, and RLY in this order
and displayed in the device selector window.

2. Select the device No.

Select the device No. of the selected device type using the and keys.
Together with the device No., its current value and set value (upper limit value in
the case of TRM) are displayed.

If the selected device type is DM, T/C, or RLY, the numeric value addition (sub-
traction) speed is increased when the / key is pressed and held for 2 seconds
or more.

➮ Refer to "Turbo function" (p.1-83)

Selected device type

Device No.
