7.6 Display Interface Mode Programming KV-300 Series Only
KV
-300
KV-10/80
Chapter 7 KV-L2 Serial Interface Module
1-287
1
7
■ Code list of data to force-set/-reset
■ Response format (When the command is executed normally, the response
includes the end code "00".)
Note 1: High-speed counter comparator CTC cannot be force-reset.
Note 2: The temporary memory addresses can be changed by bit.
Note 3: An underscore (_) in the instruction word represents a space. Be sure to
include the underscore in the instruction word when transmitting the command.
Note 4: The counter/timer values and high-speed counter comparator values cannot
be set or reset with a same single command at once. Set or reset these values
individually.
Note 5: The station no., ch. to change, and bit to change are indicated in decimal;
the end code, in hexadecimal.
Read values from DM0008 to DM0015 (CR)
This command reads the values from DM0008 to DM0015 with a short command.
■ Command format
■ Response format (When the command is executed normally, the response
includes the end code "00".)
Read model code (MM)
This command reads the KV-300 model code (13).
■ Command format
m Description
0, 8 No operation
2, 4 Reset
3, 5 Set
Station No.
nn
@ FK FCS ❋ C
R
End code
nn
Header code Terminator
Station No.
nn
@ CR FCS ❋ C
R
Header
code
00 to 15
(in decimal)
Terminator
@ CR FCS ❋ C
R
Station No.
nn
End code
nn
Data
nnnn Data
nnnn Data
nnnn
Header code Terminator Value of DM0015
(in hexadecimal)
Value of DM0009
(in hexadecimal)
Value of DM0008
(in hexadecimal)
Station No.
nn
@ MM FCS ❋ C
R
Header code 00 to 15
(in decimal)
Terminator
