Appendix B Specifications and Dimensions KV-300 Series
Appendicies
Appendices
1-395
For KV-10/80 users
General Sepcifications
Power supply 24 VDC (+10%-20%)
Maximum Base unit KV-10R(W): 75 mA max. KV-80T(W): 300 mA max.
Current KV-10T(2W): 65 mA max. KV-16R(W): 105 mA max.
consump- KV-24R(W): 130 mA max. KV-16T(2W): 70 mA max.
tion KV-24T(2W): 75 mA max. KV-40R(W): 220 mA max.
KV-80R(W): 400 mA max. KV-40T(2W): 115 mA max.
Expansion KV-8ER(W): 35 mA max. KV-8EYT: 60 mA max.
unit KV-8ET(2W): 20 mA max. KV-16EX(W): 25 mA max.
KV-8EX(W): 15 mA max. KV-16EYR(W): 150 mA max.
KV-8EYR(W): 80 mA max. KV-16EYT(W): 100 mA max.
Others KV-P3E(01): 65 mA
Ambient temperature 0 to 50 °C (32 to 122°F)
(No freezing) 0 to 45 °C (32 to 113°F) [KV-P3E(01)]
Relative humidity 35 to 85%, No condensation
Withstand voltage 1500 VAC applied between power terminal and I/O terminal,
and between terminals and housing (1min)
Noise immunity Noise generated by noise simulator:
1kV p-p max., 1 ms and 50 ns
Vibration 10 to 55 Hz, double amplitude of 1.5 mm max.
applied in each of X, Y, and Z directions (2 hrs)
Insultation resistance 50 mΩ min. between power terminal and I/O
terminal, and external terminals and housing
(measured by 500 VDC megohmmeter)
Environment No excessive dust or corrosive gas allowed
Weight Base unit KV-10R(W): approx. 130 g KV-80T(W): approx. 500 g
KV-10T(2W): approx. 120 g KV-24R(W): approx. 250 g
KV-16R(W): approx. 200 g KV-24T(2W): approx. 220 g
KV-16T(2W): approx. 180 g KV-40R(W): approx. 340 g
KV-80R(W): approx. : 600 g KV-40T(2W): approx. 270 g
Expansion KV-8ER(W): approx. 120 g KV-8EYR(W): approx. 140 g
unit KV-8ET(2W): approx. 100 g KV-8EYT(2W): approx. 130 g
KV-8EX(W): approx. 130 g KV-16EYR(W): approx. 240 g
KV-16EX(W): approx. 180 g KV-16EYT(W): approx. 190 g
Others KV-P3E(01): approx. 230 g
■ Input specifications
Rated voltage and current 24 VDC 7 mA (terminals 000 to 005)
5 mA (other terminals)
Threshold voltage (ON) 19 V
Threshold current (OFF) 2 mA
Response time 25 µs/8 to 12 ms (OFF → ON)
(selectable by program) 75 µs/8 to 12 ms (ON → OFF)
Interrupt response time 25 µs (OFF → ON)
(terminals 000 to 003) 35 µs (ON → OFF)
High speed counter response time 10 kHz max.
