7.6 Display Interface Mode Programming KV-300 Series Only
KV
-300
KV-10/80
Chapter 7 KV-L2 Serial Interface Module
1-284
7
■ Command format
* An instruction word is specified with uppercase alphabetical characters.
An underscore (_) represents a space.
■ Response format (When the command is executed normally, the response
includes the end code "00".)
Note 1: An underscore (_) in the instruction word represents a space. Be sure to
include the underscore in the instruction word when transmitting the command.
Note 2: A set value exceeding 10000 cannot be specified.
The station no. is indicated in decimal; the end code, in hexadecimal.
Read KV-300 CPU operation mode (MS)
This command reads the KV-300 CPU operation status.
■ Command format
■ Response format (When the command is executed normally, the response
includes the end code "00".)
Change KV-300 CPU operation mode (SC)
This command changes the KV-300 CPU operation mode.
■ Command format
Station No.
nn
@ W# FCS ❋ C
R
Instruction
word
xxxx
Operand
nnnn
New set
value
nnnn
Header code 00 to 15
(in decimal)
Terminator 0000 to 9999
(in decimal)
Instruction word Operand Data
CNT_ 0000 to 00249 Counter/timer
TIM_
CNT_ 0250 to 0253 High-speed counter comparator
@ W# FCS ❋ C
R
Station No.
nn
End code
nn
Header code Terminator
Station No.
nn
@ MS FCS ❋ C
R
Header
code
00 to 15
(in decimal)
Terminator
Station No.
nn
@ MS FCS ❋ C
R
End code
nn
Operation
mode
nnnn
Header code Terminator RUN mode: 0061,
PROGRAM mode: 0261
Station No.
nn
@ SC FCS ❋ C
R
Operation
mode
nn
Header code Terminator
