3.4 Device Mode
Chapter 3 Access Window
1-91
1
3
Visual KV
Series
Holding the setting
• Even if the device mode is changed to another mode, the device type and device
No. selected just before the mode change are retained. Device Nos. of other
devices are also retained. When the device type is changed in the device mode,
a selected device No. for each device type is also held.
• When the power is turned off, just the device No. of the selected device type is
held only if the device mode was selected just before the power was turned off.
The held device No. will automatically be displayed when the power is next
turned on. If any mode other than the device mode was selected just before
turning the power off, or if "LoAd" is executed in the system mode, DM will be
automatically selected when the power is next turned on, and the device mode
will be selected.
3.4.2 Screen Display for Each Device Type
This section describes differences in the set value range and the screen display
among device types in the numeric value change status.
Data memory (DM)
• While the device No. is selected, three types of turbo functions (quick, turbo, and
super turbo) are available.
• The upper limit values of the trimmers Nos. 0 and 1 are written to DM1938 and
DM1939, respectively.
• If an entered current value is larger than the upper limit value, the current value
change is canceled.
Temporary data memory (TM)
• While the device No. is selected, no turbo function is available.
Device No.: 0 to 1999
Current value
Device No.: 0 to 31
Current value
