Kv-e4r/e8r/e16r (relay output type), Visual kv series – KEYENCE Visual KV Series User Manual
Page 68
Chapter 1 Configuration and Specifications
1-44
1
Visual KV
Series
1.9 KV-E4R/E4T/E8R/E8T(P)/E16R/E16T(P) (Expansion Output Unit)
KV-E4R/E8R/E16R (Relay output type)
➮ For more about the general specifications, refer to "General Specifications" (p.1-4).
