Chapter 4 KV-D20 Operator Interface Panel
1-139
1
4
Visual KV
Series
Displaying current and preset values of counter simultaneously
Operator screen Ladder program
Description
• Display the current and preset values of C100 simultaneously. The upper line is
the current value, and the lower line is the preset value.
Comment
Changing devices to be displayed
Operator screen
Ladder program
Description
Change the displayed device by pressing customized switches F1 and F2.
Comment
F1 F2 F3 F4
1 2 3 4
PRESET
2002 #21100
DM1580
DW
$0000
DM1680
DW
Counter C100
Device No. Comment 1
F1 F2 F3 F4
1 2 3 4
F1 F2 F3 F4
1 2 3 4
ACCEPTABLE: DEFECTIVE:
Counter
C000
C001
Device No. Comment 1
A C C E P TA B L E
D E F E C T I V E
2500 2501 #21000
DM1580
DW
$1000
DM1680
DW
2500 2501 #21001
DM1580
DW
$1000
DM1680
DW
4.3 Examples of Ladder Programs
