7.5 KV Mode Programming KV-300 Series Only
KV
-300
KV-10/80
Chapter 7 KV-L2 Serial Interface Module
1-257
1
7
Function Command Response Remarks
Reads timer RD_Tnnn f,ddddd,ddddd f=0, 1 0: contact OFF
(current value) ddddd=00000 to 65535)
(preset value) (in decimal nnnn=timer no.
Reads analog RD_AT ddddd_ddddd_ ddddd=00000 to 00249
timer 00000_00000 (in decimal)
(Trimmer 0) Reads values of trimmers 0 and
(Trimmer 1) 1.
Changes current WR_Cnnn_ OK n/nnn: counter/timer no.
value of timer/ ddddd ddddd=00000 to 65535
counter WR_CTHn_ (in decimal)
ddddd
WR_Tnnn_
ddddd
Changes preset WS_Cnnn_ OK n/nnn: counter/timer no.
value of timer/ ddddd ddddd=00000 to 65535
counter WS_CTCn_ (in decimal)
ddddd
WS_Tnnn_
ddddd
Reads relay RD_nnnnn 0 0: contact OFF
contact 1 1: contact ON
Forces contact ON ST_nnnnn OK nnnnn=relay no.
ST_Cnnn nnn=counter /timer no.
ST_Tnnn
Forced contact OFF RS_nnnnn OK nnnnn=relay no.
RS_Cnnn nnn=counter /timer no.
RS_CTCn n=high-speed counter comparator
RS_Tnnn no.
Reads DM RD_DMnnnn ddddd ddddd=00000 to 65535
(in decimal)
nnnn=DM no.
Writes into DM WR_DMnnnn_ OK ddddd=00000 to 65535
ddddd (in decimal)
nnnn=DM no.
Reads TM RD_TMnn ddddd ddddd=00000 to 65535
(in decimal)
nn=TM no.
Writes into TM WR_TMnn_ OK ddddd=00000 to 65535
ddddd (in decimal)
nn=TM no.
An underscore (_) in the command represents a space.
TM30 and TM31 are read-only memories; values cannot be written to them.
Note: The "WS" command changes the content of the program stored in the PLC's
EEPROM. Contact Keyence if you need to change it frequently.
