7.6 Display Interface Mode Programming KV-300 Series Only
KV
-300
KV-10/80
Chapter 7 KV-L2 Serial Interface Module
1-285
1
7
■ Response format (When the command is executed normally, the response
includes the end code "00".)
Set (KS)
This command sets the ON/OFF status of the specified channel of the I/O relay,
internal utility relay, temporary memory address, timer, counter, or high-speed
counter comparator.
■ Command format
* An instruction word is specified with uppercase alphabetical characters.
An underscore (_) represents a space.
■ Response format (When the command is executed normally, the response
includes the end code "00".)
Note 1: High-speed counter comparator CTC cannot be force-reset.
Note 2: The temporary memory address can be changed by bit.
Note 3: An underscore (_) in the instruction word represents a space. Be sure to
include the underscore in the instruction word when transmitting the command.
Note 4: The station no., ch. no. to change, and bit to change are indicated in
decimal; the end code, in hexadecimal.
Reset (KR)
This command resets the ON/OFF status of the specified channel of the I/O relay,
internal utility relay, temporary memory address, timer, counter, or high-speed
counter comparator.
Operation mode Description
00 PROGRAM mode
01, 02, 03 RUN mode
@ SC FCS ❋ C
R
Station No.
nn
End code
nn
Header code Terminator
Station No.
nn
@ KS FCS ❋ C
R
Device
xxxx
Ch. no. to
change
nnnn
Bit to
change
nn
Header code 00 to 15
(in decimal)
Terminator
Device Ch. No. to change Bit to change Data
CIO_ 0000 to 0179 00 to 15 I/O relay, internal utility relay
HR_ _ 0000 to 0031 00 to 15 Temporary memory address
AR_ _ 0000 to 0179 00 to 15 I/O relay, internal utility relay
TIM_ 0000 to 0249 00 Timer
CNT_ 0000 to 0249 00 Counter
@ KS FCS ❋ C
R
Station No.
nn
End code
nn
Header code Terminator
