6.4 Memory Card
Chapter 6 Handheld Programmer
1-230
6
Function Description
CLEAR Initializes memory card. (required when using new memory
card.)
Deletes all programs in memory card.
NEW Writes new program into memory card.
Manages programs based on their names (3 of any characters
in hex: 0 to 9 and A to F) and dates.
ACCS SAVE Overwrites program on programmer onto desired program in
memory card.
LOAD Retrieves desired program from memory card.
VERIFY Compares desired programs on programmer and in memory
card.
DELETE Deletes desired program in memory card.
6.4 Memory Card
Memory card M-2/M-3 can store programs created on the handheld programmer
KV-P3E(01) or on a personal computer (using the programming support software KV
IncrediWare (DOS) and card reader/writer Z-1). These programs can be transferred
to the PLC.
6.4.1 Functions [used with KV-P3E(01)]
• The memory card stores all programs including those written after ENDH instruc-
tion. (NOP instruction is not included.)
• One memory card can store programs used on different KV PLCs.
• The memory card can only be used in the handheld programmer when the mode
switch on this programmer is set to PROGRAM or when the OFFLINE EDITOR is
used.
• Each program must have a name distinct from other programs stored in the
memory card.
6.4.2 Storage Capacity
The M-2 and M-3 have the following storage capacity:
1 block is made of 256 bytes.
Model Capacity Number of programs
M-2 32 Kbytes 24 programs max. (total number of blocks: 125 max.)
M-3 128 Kbytes 48 programs max. (total number of blocks: 506 max.)
