6.3 Functions
Chapter 6 Handheld Programmer
1-218
6
Key operation Display Description
00000
Display arbitrary line.
LD 00000
HI-SPEED CTR CL Access HIGH SPEED COUNTER
EXEC. OK? CLEAR [HIGH SPEED CTR CLR] function.
Execute HIGH SPEED COUNTER.
COMPLETED
00000
Return to initial display.
LD 00000
FNC ORB
6
ENT
R-SRCH
CLEAR
ENT
R-SRCH
ORL
3
COUNTER CLEAR (CTR CLEAR) [FNC62] PROGRAM mode
Function
Performs following operation:
•
Counter (C*** #*****):
The current value is reset to "0". The contact turns OFF.
• Up-down counter (UDC*** #*****):
The current value is reset to "0". The contact turns OFF.
Key operation
Basic operation
Example of operation
HIGH-SPEED COUNTER CLEAR PROGRAM mode
(HIGH-SPEED CTR CLR) [FNC63]
Function
Performs following operation:
•
High-speed counter (CTH* *****):
The current value is reset to "0".
• High-speed counter comparator (CTC* #*****):
The contact turns OFF.
Key operation
Basic operation
Example of operation
ORB
6
ANL
2
ENT
R-SRCH ENT
R-SRCH FNC
Key operation Display Description
00000
Display arbitrary line.
LD 00000
CTR CLEAR Access COUNTER CLEAR [CTR CLEAR]
EXEC. OK? function.
Execute COUNTER CLEAR.
COMPLETED
00000
Return to initial display.
LD 00000
FNC
ORB
6
ENT
R-SRCH
CLEAR
ENT
R-SRCH
ORB
6
ORL
3
ENT
R-SRCH ENT
R-SRCH
FNC
ANL
2
