1.7.5 Dimensions
■ Main unit
■ Metal fixture for screw tightening
22 43
35.4 90
4 3.8
22 70
35.4 90
4 3.8
20.5
17.5
110
20.5
20.2
31
Front view Side view (KV-40AR/AT(P)) Side view (KV-40DR/DT(P))
Bottom view (KV-40AR/AT(P))
111 99
78
109
4-ø5.0
Main unit
mounting hole*
(2 positions)
(Mounting
hole)
1.7 KV-40AR/AT(P)/DR/DT(P) (40-I/O Basic Unit)
t=2
* Two M3.5 countersunk-head screws
are included for mounting the main unit.
