Appedix C. Ladder Program List Visual KV Series only
Appendicies
Appendices
1-406
Appendix C. Ladder Program List
The following is a list of instructions and the reference pages that give the application
examples for the instructions.
Instruction
Reference
page
ANL 3-61
ORL 3-63
One-shot circuit 3-70
Off-delay circuit 3-70
On-delay circuit 3-71
Flicker circuit 3-71
Long-duration timer 3-74
Accumulator timer (Retained during power failure) 3-74
Large capacity timer 3-74
Multi-level setting 3-74
Counter multi-level setting 3-75
Multi-level UP/DOWN counter 3-77
One-shot circuit using differentiate instruction 3-79
Alternating circuit (DIFU instruction) 3-79
Detection of chewing gum packs 3-81
Alternating circuit (SFT instruction) 3-83
Resetting internal utility relays 3-84
Repeat shift circuit 3-84
Asynchronous shift register 3-85
High-speed fetching of input data 3-88
Emergency stop circuit 3-91
Input sequence check 3-101
Fork lift truck IN/OUT judgement 3-101
MPS/MRD/MPP 3-104
Enabling double coil 3-112
Conditional branching 3-113
Process progression 3-116
Pulse interval measurement 3-120
A/D data measurement 3-121
Nesting structure of subroutine 3-123
Calling subroutine from interrupt program 3-124
Data memory shift 3-130
Changing preset value of internal counter using BCD digital switch 3-132
Changing timer setting value 3-139
Changing setting values of multiple timers 3-139
Changing the counter setting value 3-141
Transferring current counter value to data memory 3-142
Transferring content of data memory as setting value of a timer 3-142
Outputting input (ON/OFF status) of basic unit directly to 3-143
expansion output unit
When BCD digital switch (2 digits) is connected to inputs 0000 through 3-144
0007 and toggle switch is connected to inputs 0008 through 0015
First-in first-out (FIFO) 3-145
Multi-level counter 3-148
When comparing values with no specific range 3-148
Setting the upper/lower limit 3-149
Changing the CMP setting value 3-149
Visual KV Series only
