Chapter 2 System Installation
1-70
2
Visual KV
Series
2.2
Connecting Visual KV Series
Expansion Units
This section describes the method to connect Visual KV Series expansion units to a
Visual KV Series basic unit and the various functions of expansion units.
2.2.1
Visual KV Series Expansion Units
Visual KV Series expansion input units
Visual KV Series expansion output units
Visual KV Series expansion I/O units
KV-E4X
KV-E8X
KV-E16X
KV-E4R
KV-E8R
KV-E16R
KV-E4T
KV-E8T(P)
KV-E16T(P)
KV-E4XR
KV-E4XT(P)
2.2 Connecting Visual KV Series Expansion Units
KVHKA Chap 02.p65
08.3.11, 11:11 AM
70
