3.3 Digital Trimmer Mode
Chapter 3 Access Window
1-84
3
Visual KV
Series
3.3
Digital Trimmer Mode
The setting method for Analog Timer (TMIN: Trimmer in) is changed from conven-
tional analog method to digital method, which allows for more detailed settings. This
section describes the function and the operating procedure of the digital trimmer
mode.
3.3.1
Function and Operating Procedure
Key operation and screen display
The table below shows the function for each key in the digital trimmer mode.
Function and operating procedure
The Visual KV basic unit is equipped with two trimmers, trimmer No. 0 and trimmer
No. 1. The trimmer No. can be selected and a numeric value can be set using the
setting operation keys. The maximum set value for each trimmer is 65,535.
■ Operating procedure
1. Select the trimmer No.
Each time the key is pressed, trimmer No. 0 and trimmer No. 1 is selected
alternately.
Trimmer No.
Increment (decrement)
quantity
Selected device type
(TRM (= trimmer)
only in this mode)
Current value
Upper limit value
