Appendix B Specifications and Dimensions KV-300 Series
Appendicies
Appendices
1-392
Appendix B. Specifications and Dimensions
[KV-300 Series]
B.1 System Specifications [KV-300 Series]
Hardware
Note: Specifications for the KV-AN6 and KV-L2 appear in their respective sections in
this manual.
Use only the specified cable when connecting to terminal modules. Use of any
other cable may cause communication errors.
CAUTION
Item/Model Specifications
Power supply 24 VDC (±10%)
CPU KV-300: 160 mA
Input module KV-C16X: 15 mA KV-C32X: 15 mA
Output module KV-C32T: 55 mA KV-B16R: 150 mA
KV-B16S: 85 mA
KV-R1A: 75 mA KV-R8X: 25 mA
KV-R8R: 85 mA KV-R8T: 35 mA
KV-R16X: 30 mA KV-R16R: 150 mA
KV-R16T: 50 mA ➮ See [Caution]
KV-P3E(01): 65 mA (Models sold after Oct. 21,
1993, are compatible with the KV-300.)
Ambient temperature 0 to 50°C (32 to 122°F)
(No freezing) 0 to 45°C (32 to 113°F) (KV-P3E(01))
Relative humidity 35 to 85%, No condensation
Withstand voltage 1500 VAC applied between power terminal and
I/O terminals, and between terminals and
housing (1 min.), but not between power supply
unit and KV-AN6
Noise immunity Noise generated by noise simulator: 1500 V p-p
min. 1 µs and 50 ns
Vibration 10 to 55 Hz. Double amplitude of 1.5 mm max.
applied in X, Y, and Z directions (2 hrs)
1G when mounted to DIN rail
Minimum insulation resistance 50 MΩ between power terminal and I/O
terminals, and between external terminals and
housing (measured with 500 VDC
megohmmeter)
Environmental restrictions No excesive dust or corrosive gas
CPU KV-300: 110 g
Input module KV-C16X: 80 g KV-C32X: 95 g
Output module KV-C32T: 70 g KV-B16R: 200 g
KV-B16S: 200 g
I/O distribution module KV-R1A: 100 g
KV-R8X: 130 g
KV-R8R: 160 g
KV-R8T: 130 g
KV-R16X: 180 g
KV-R16R: 240 g
KV-R16T: 180 g
KV-U4: 340 g KV-U5: 90 g
Maximum current
consumption
(Excluding
current for
Handheld Pro-
grammer and
input circuit)
I/O distribution
module
Handheld
programmer
Weight
(Approx.)
AC Power supply
module/ DC power
distribution module
