KEYENCE Visual KV Series - Manual (Page 433)

Appendix D. A/D and D/A Conversion Tables [KV-AN6]
Appendicies
Appendices
1-409
Current conversion table
■ 0-to-20 mA range
■ 4-to-20 mA range
.00 .10 .20 .30 .40 .50 .60 .70 .80 .90
+20 32000 32320 32640
+19 28800 29120 29440 29760 30080 30400 30720 31040 31360 31680
+18 25600 25920 26240 26560 26880 27200 27520 27840 28160 28480
+17 22400 22720 23040 23360 23680 24000 24320 24640 24960 25280
+16 19200 19520 19840 20160 20480 20800 21120 21440 21760 22080
+15 16000 16320 16640 16960 17280 17600 17920 18240 18560 18880
+14 12800 13120 13440 13760 14080 14400 14720 15040 15360 15680
+13 9600 9920 10240 10560 10880 11200 11520 11840 12160 12480
+12 6400 6720 7040 7360 7680 8000 8320 8640 8960 9280
+11 3200 3520 3840 4160 4480 4800 5120 5440 5760 6080
+10 0000 320 640 960 1280 1600 1920 2240 2560 2880
+9 62336 62656 62976 63296 63616 63936 64256 64576 64896 65216
+8 59136 59456 59776 60096 60416 60736 61056 61376 61696 62016
+7 55936 56256 56576 56896 57216 57536 57856 58176 58496 58816
+6 52736 53056 53376 53696 54016 54336 54656 54976 55296 55616
+5 49536 49856 50176 50496 50816 51136 51456 51776 52096 52416
+4 46336 46656 46976 47296 47616 47936 48256 48576 48896 49216
+3 43136 43456 43776 44096 44416 44736 45056 45376 45696 46016
+2 39936 40256 40576 40896 41216 41536 41856 42176 42496 42816
+1 36736 37056 37376 37696 38016 38336 38656 38976 39296 39616
0 33536 33856 34176 34496 34816 35136 35456 35776 36096 36416
.00 .10 .20 .30 .40 .50 .60 .70 .80 .90
+20 32000 32320 32640
+19 28000 28400 28800 29200 29600 30000 30400 30800 31200 31600
+18 24000 24400 24800 25200 25600 26000 26400 26800 27200 27600
+17 20000 20400 20800 21200 21600 22000 22400 22800 23200 23600
+16 16000 16400 16800 17200 17600 18000 18400 18800 19200 19600
+15 12000 12400 12800 13200 13600 14000 14400 14800 15200 15600
+14 8000 8400 8800 9200 9600 10000 10400 10800 11200 16000
+13 4000 4400 4800 5200 5600 6000 6400 6800 7200 7600
+12 0000 400 800 1200 1600 2000 2400 2800 3200 3600
+11 61536 61936 62336 62736 63136 63536 63936 64336 64736 65136
+10 57536 57936 58336 58736 59136 59536 59936 60336 60736 61136
+9 53536 53936 54336 54736 55136 55536 55936 56336 56736 57136
+8 49536 49936 50336 50736 51136 51536 51936 52336 52736 53136
+7 45536 45936 46336 46736 47136 47536 47936 48336 48736 49136
+6 41536 41936 42336 42736 43136 43536 43936 44336 44736 45136
+5 37536 37936 38336 38736 39136 39536 39936 40336 40736 41136
+4 33536 33936 34336 34736 35136 35536 35936 36336 36736 37136
