Chapter 1 Configuration and Specifications 1-27
1
1
Visual KV
Series
KV-24AT(P)/DT(P) (Transistor output type)
■ Terminal layout drawing
■ Input circuit diagram
1.6 KV-24AR/AT(P)/DR/DT(P) (24-I/O Basic Unit)
C1 001 003 005 007 009 011 013 015
000 002 004 006 008 010 012 014
24V 0V C3 R500 R501 R502 V3 505 507
V1 V2 500 501 502 503 504 506
005
006
007
008
009 011 015
004 002 000 010 012 014
C1 001 003 013
Internal circuit
Three-wire
type
Blue
Black Brown
Three-wire
type
Blue
Black Brown
Three-wire
type
Blue
Black Brown
Three-wire
type
Blue
Black Brown
Three-wire
type
Blue
Black Brown
Three-wire
type
Blue
Black Brown
Three-wire
type
Blue
Black Brown
Three-wire
type
Blue
Black Brown
Three-wire
type
Blue
Black Brown
Three-wire
type
Blue
Black Brown
Three-wire
type
Blue
Black Brown
Three-wire
type
Blue
Black Brown
Three-wire
type
Blue
Black Brown
Three-wire
type
Blue
Black Brown
Three-wire
type
Blue
Black Brown
Three-wire
type
Blue
Black Brown
Sensor
000 to 007
C1
4.3 kΩ
008 to 015
C1
4.3 kΩ
510Ω
Circuit configuration of inputs 000 to 007
Photocoupler
insulation
24V/5V
selector
circuit
Internal circuit
Circuit configuration of inputs 008 to 015
Photocoupler
insulation
Internal circuit
