4. Control panel (only type MTR-DCI-...-H2)
4-20
Festo P.BE-MTR-DCI-CO-EN en 1209a
4.5.4
[Settings] [Position set]
Programming the position record table
•
Select the number of the desired position set. The follow-
ing settings refer to the currently selected position set.
Note also the instructions on programming the position
sets in chapter 5.2.5.
[Position set]
Param.
Description
[Position no.]
No.
Number of the position set
[Pos set mode]
[absolute/
relative]
Positioning mode
absolute = absolute position specification, related to the
project zero point
relative = relative position specification, related to the current
position
[Position]
xt
Teach mode for setting the target position in the selected
measuring system e.g. [mm].
Do not teach the positions until the reference system has been
defined by means of a reference run. (see chapter 4.4.3)
[Velocity]
v
Positioning speed in the selected measuring system e.g. [mm/s]
[SAVE...]
Save parameters in EEPROM
Tab. 4/9: Menü [Settings] [Position set]
<- ->
You can move the axis into the desired position or
select the parameter setting with the arrow buttons.
OK
You can accept the selection with the
ESC
With the
