A. Technical appendix
A-15
Festo P.BE-MTR-DCI-CO-EN en 1209a
Parameters MTR-DCI-32 MTR-DCI-42 MTR-DCI-52 MTR-DCI-62
feed 1) DMES-18-...:
1500 [μm/red] DMES-25-...:
2500 [μm/red] DMES-40-...:
4000 [μm/red] DMES-63-...:
6000 [μm/red]
enc 2) 300 x 4 =
1200 [incr/rev] 500 x 4 = 2000 [incr/rev]
gear 3) MTR-DCI-...-G7 (6.75:1) > 27:4
MTR-DCI-...-G14 (13.73:1) > 3969:289
MTR-DCI-...-G22 (22.2:1) > 1710:77
1) Feed constant: dependent on the axis type, here DMES-...
2) Encoder resolution for MTR-DCI: impulse four-fold multiplication through digital interpolation
3) Gear reduction: specification in 2 real numbers for numerator or denominator of the fraction
Tab. A/1: Basis parameter for the measuring system
Drive Conversion factors UF
Increments < > millimetres
Increments = millimetres*UF
Millimetres = increments/UF
Increments < > inch
Increments = inches*UF
Inches = increments/UF
MTR-DCI-32...
(+DMES-18) -G7
-G14 5400
10986.851211 13716
27906.602076
MTR-DCI-42...
(+DMES-25) -G7
-G14 5400
10986.851211 137160
27906.602076
MTR-DCI-52...
(+DMES-40) -G7
-G14 3375
6866.782007 85725
17441.626298
MTR-DCI-62...
(+DMES-63) -G7
-G14
-G22 2250
4577.854671
7402.597403 57150
11627.750865
18802.597403
Tab. A/2: Special conversion factors for the MTR-DCI with DMES-...
