4. Control panel (only type MTR-DCI-...-H2)
4-17
Festo P.BE-MTR-DCI-CO-EN en 1209a
4.5.1 [Settings] [Axis type]
Select the axis driven by the MTR-DCI
[Axis type] Description
[Type DMES-...] Festo servo axis
[Type DNCE-...] Festo electrocylinder
[Rotation drive] Specific rotation axis
[User config] Specific linear axis
Tab. 4/6: Menü [Settings] [Axis type]
<- -> With the arrow keys you can set the axis-specific
features e.g. feed constant, measuring system or
counting direction according to the entry request.
(details see chapter 5.2.1).
SAVE You can save the settings permanently in EEPROM
with the button
ESC With the
• Save the settings with SAVE .
