4. Control panel (only type MTR-DCI-...-H2)
4-16
Festo P.BE-MTR-DCI-CO-EN en 1209a
4.5 Menu [Settings]
The menu [Settings] contains all functions necessary for
parametrizing the axis system and the position sets. Further
iinformation on the individual menu commands can be found
in the chapters specified (see Tab. 4/5).
1. Select the menu [Settings] in the main menu.
2. Select a menu command.
[Settings] Description Chapter
[Axis type] Select the axis driven by the MTR-DCI 4.5.1
[Axis parameter] Teach mode for setting the axis parameters 4.5.2
[Homing paramet.] Setting the reference travel method and the speed during
reference travel 4.5.3
[Position set] Teach mode for programming the position record table 4.5.4
[Password edit] Setting up a local password with 3 figures for the control panel 4.5.5
[CAN parameter] Setting the field bus parameters 4.5.6
Tab. 4/5: Menu [Settings]
Note
The set parameters take effect immediately after confirma-
tion with OK . The settings are saved permanently
in EEPROM with the [SAVE...] menu command:
• Choose [SAVE...] to save the parameter settings. Only
then will the settings be retained even when the power
supply is switched off or if there is a power failure.
} Settings
Axis type
Axis parameter
Homing paramet.
Position set
Password edit
CAN parameter
