C. Reference – CANopen and CI objects
C-17
Festo P.BE-MTR-DCI-CO-EN en 1209a
Transmit PDO communication parameter
CANopen 1800h,
1801h 01h...05h Record uint32, uint8, uint16 rw
Description Communication parameters of PDOs 1 and 2 which the device can transmit:
– PDO 1:
Object 1800h
– PDO 2: Object 1801h
COB-ID for PDO 1800h,
1801h
01h uint32 rw
COB ID used by the PDO.
– PDO 1:
Default: 0x180 + Node-ID
– PDO 2: Default: 0x280 + Node-ID
Transmission type 1800h,
1801h
02h uint8 rw
Transmission type
Default: 255 (0xFF) – Event-triggered asynchronous transmission
Value range: 0 ... 255 (0x00 ... 0xFF)
Inhibit time 1800h,
1801h
03h uint16 rw
Inhibit time.
Fixed: 0 (0x0000)
Compatibility entry 1800h,
1801h
04h – –
Reserved, must not be implemented (access attempts are answered with
abort code).
Event timer 1800h,
1801h
05h uint16 rw
Event counter in [ms].
Default: 0 (0x0000)
