3. Installation
3-5
Festo P.BE-MTR-DCI-CO-EN en 1209a
The plug connectors on the Festo cables listed in the follow-
ing are designed to conform to protection class IP54 when
connectors are plugged in and secured, or when the connec-
tions on the MTR-DCI are equipped with protective caps.
Caution
Long lines reduce immunity to interference (EMC).
• Observe the specified maximum cable lengths.
Connection Cable Designation Length [m]
Serial interface Programming cable KDI-MC-M8-SUB-9-2,5 2.5 (max. 2.5)
Reference switch Connecting cable KM8-M8-GSGD-... 0.5 / 1 / 2 / 5
Voltage supply Power supply cable KPWR-MC-1-SUB-9HC-... 2.5 / 5 / 10
(max. 10)
Power supply Supply cable KPWR-MC-1-SUB-9HC-... 2.5 / 5 / 10
(max. 10)
Tab. 3/2: Overview of cables (accessories)
Complying with the IP protection class
• Seal unused M8 connections with ISK-M8 protective caps
(accessories),
• Tighten the union nuts/locking screws on the plugs by
hand.
Observe the permissible torques specified in the documenta-
tion for the cables and connectors used.
