4. Control panel (only type MTR-DCI-...-H2)

4-8

Festo P.BE-MTR-DCI-CO-EN en 1209a

4.3

[Diagnostic] menu

In order to display the currently effective settings in the
positioning set table, axis and system parameters as well as
status and diagnostic information for bus communication and
for firmware version:

1. Select the [Diagnostic] menu in the main menu.

2. Select a menu command (see Tab. 4/3 and Tab. 4/4).

<- ->

You can scroll through the data with the arrow
buttons.

ESC

With the

button you can return to the
higher-order menu.

} Diagnostic

Pos.set table
Axis parameter
System paramet.
CAN-BUS Diag
Sodtware
information
