6. Diagnostics and error display
6-8
Festo P.BE-MTR-DCI-CO-EN en 1209a
Cate-
gory Status
bytes
2)
Fault
LED Fault
number Device
error
1)
Description Name, display
War-
ning HOT TEMPERATURE Overheating – – FLASHES WARN
War-
ning COLD
TEMPERATURE Under temperature – – FLASHES WARN
1) see PNU 205/CO 2FF1/00
2) FHPP status bytes, see section 5.5.2
Tab. 6/6: Faults and warnings with fault numbers and fault bits
6.3.2 Description of the messages, warnings and faults
Messages Messages inform about operating states.
Message Cause
Attention Motor
moves... Message before the start of a positioning move-
ment. After confirmation with the button
the drive moves.
Profile velocity
= 0. Please set
v. The menu command [Move position set] is not
processed because the positioning speed of the
positioning set v = 0. Modify the parametrizing or
select a different postioning set.
