3. Installation
3-20
Festo P.BE-MTR-DCI-CO-EN en 1209a
3.7.3 Bus termination with terminating resistors
Note
If the MTR-DCI is at the beginning or end of the field bus
segment, a bus termination will be required.
• Always use a bus termination at both ends of the field
bus.
If the MTR-DCI is to be connected at the end of the fieldbus, a
terminating resistor (120 Ω, 0.25 W) must be installed in the
fieldbus socket:
• Connect the terminating resistor between the cores for
CAN_H and CAN_L.
