6. Initial Setting and Position Data Editing for SEP
Controllers
79
6.2 Editing Position Data
6.2.1 Online Mode
In this mode, data is read from the controller and edited.
The window is different according to each operation pattern.
Click Position from the main menu and select Edit/Teach, or click the button.
In the axis selection window, select the axis number corresponding to the position data you want to edit. Refer
to 4, “Selecting an axis.”
If the position data edit password is not “0000,” the input password window appears. Enter the password.
* The factory-set password is “0000.” If the factory-set password is valid, the input password window does not
appear.
Fig. 6.8 Input Password Window
