5. Editing Position Data on CON Controllers and Older Models
70
5.2.2 Reading a File
To read position data from a file, click File and then select Open to open the “Open” window. Alternatively, you
can click File, point to Send to Controller and then select Position to open the “Open” window.
Fig. 5.33 “Open” Window
Select (click) “File name” you want to open, and click Open on the “Open” window, then the position data edit
window is displayed.
Position data can be edited offline.
Fig. 5.34 Position Data Edit Window (Offline Mode)
Select folder in which
position data is saved. Saved file name
Select controller.
Tool buttons
Position data input area
