11. Smart T
uning Function (V
ersion V8.03.00.00 or Later)
164
Tool Button
Fig. 11.82 Tool Button (Takt Time Calculation Window)
Zoom in/out of Vertical Axis
Click this button to zoom in/out the vertical axis of the operation graph.
Zoom in/out of Horizontal Axis
Click this button to zoom in/out the horizontal axis of the operation graph.
Displayed Data Switchover
The data (velocity/position) shown on the takt time calculation result graph can be
switched over with this radio button.
Test run Result Graph
Fig. 11.84 Test run result Graph (Velocity response)
The data selected with the check box on the displayed data switchover radio button can be
shown.
