7. Editing Parameters
94
7. Editing Parameters
To load parameter data from the controller, click Parameter (P) and then select Edit (E) from the main menu,
or click in the toolbar. In the “Select axis number” window, select the axis number corresponding to the
axis whose parameters you want to edit. (Refer to 4, “Selecting an Axis.”)
* On the versions V7.0.3.0 or later, the default password is “0000”, so the input password window will not
appear.
* On the versions V7.00.1.00/V7.00.2.00, the default password is “5119.” Enter “5119” and click the OK button.
Fig. 7.1 Input Password Window
To change the password, perform the operations explained below.
[How to Set Password]
[1] From the main menu, click Setting and then select Application.
Click the Change Password button.
Fig. 7.2 Setting of Application Window
[2] If you are using a CON controller, select “System Password” and then click the OK button.
This window does not appear if you are using a SEP controller.
Fig. 7.3 Select Password Window
[3] Enter the current password, new password, and new password again (for confirmation),
and then click the OK button.
Once the new password has been set, you must enter the new password to edit parameter data.
Fig. 7.4 System Password Change Window
