6. Initial Setting and Position Data Editing for SEP
Controllers
73
[How to Set Initial Password]
* The password should be the same as the one used for editing parameters.
When the password set here is changed, the parameter edit password will also change to the new password.
[1] From the main menu, click Setting and then select Application.
Click the Change Password button.
Fig. 6.2 Setting of Application Window
[2] Enter the current password, (the default password is “0000” for Version V7.00.03.00 or later, or "5119" for
Version V7.00.01.00/V7.00.02.00), new password, and new password again (for confirmation), and then
click the OK button.
Fig. 6.3 System Password Window
Select a desired operation pattern in the IO pattern select window, and then click OK.
(Note) When connected to MSEP Controllers, 6: Positioner Mode is displayed. If 6: Positioner Mode is
selected, it is not necessary to have the initial setting process. The initial setting window would not
appear.
Fig. 6.4 IO Pattern Select Window
