3. Main W
indow
32
3.1 Operating from the Main Menu
(1) File
[1] [New]
Create new position data.
[2] [Open]
Load position data or parameters from a file.
[3] [Close]
Close the active file.
[4] [Send to Controller] (Available in the online mode)
[Position Data]
Write position data in a file to the controller.
[Parameter]
Write parameters in a file to the controller.
[5] [Backup] (Available in the online mode)
[Save from Controller to File]
Save all position data and parameters in the controller to a file.
[Send from File to Controller]
Send all position data and parameters in a file to the controller.
[Backup data print]
Print backup data.
The following menus are added from V8.2.0.0.
[Parameter edit]
Editing is available in the parameter edit window from the backup file.
[Position data edit]
Editing is available in the position data edit from the backup file.
[Batch Backup]
The position parameter data of the axes selected from the connected multiple axes can be stored at once
to the individual file.
[Batch Restore]
The position parameter data of the files exist in the selected folders can be transferred to the controller at
once.
[6] [Recently used file]
History of recently read files are displayed, and you can select file name from these to read.
[7] [Exit]
Exit this application.
