6. Initial Setting and Position Data Editing for SEP

Controllers

77

[Types of Operation Parameters]

y

Solenoid

Select either the single-solenoid operation mode or double-solenoid operation mode.

y

Servo control

Select whether or not to use servo control (IN3 input signal SON (servo ON/OFF control)).

y

Stop signal

Select whether or not to use the pause signal *STP (input to IN2) when the single-solenoid type and

operation pattern 5 are selected.

y

Input signal mode

Select continuous current flow (level) or instantaneous current flow (edge) as the double-solenoid ON

condition when the double-solenoid type and operation pattern 4 are selected.

y

Home operation

Select a desired home return method.

y

AUTO: Home return commences when the power is input.

y

MANU: Home return commences when the ST0 signal is input for the first time after the power has been

input.

y

Output signal type

Select the signal to be output after the actuator has moved and positioning is completed.

Select either the limit switch (LS) or positioning (PE) signal.

y

Output signal

‚

When operation pattern 0, 1, 2 or 5 is selected:

‚

Select one of the following options.

Selection 1

Selection 2

Selection 3

OUT2 HEND

(home return complete signal)

SV

(servo ON output signal)

HEND

(home return complete signal)

OUT3 *ALM

(alarm output signal)

*ALM

(alarm output signal)

SV

(servo ON output signal)

‚

When operation pattern 3 or 4 is selected:

Select either *ALM (alarm) or SV (servo ON output signal) for the OUT3 output signal.

y

Intermediate position move mode

Select whether the ST0 and ST1 signals must be both ON or both OFF for the actuator to move to the

intermediate position when operation pattern 3 is set.
