12. Off Board T
uning Function on SCON-CA
Controller
194
Fig. 12.45 Test run Window (in offline work)
[1] Tuning Setting/Result Display
Fig. 12.46 Tuning Setting (When Manual) Fig. 12.47 Gain display (Test run Window)
Adjustment method select setting display
The tuning method set in “Select Tuning Method” window is displayed.
(Note) The display differs depending on the selected tuning method. The display for the modes other
than the Manual is as shown below.
Fig. 12.48 Tuning Setting
(at base ctrl band)
Fig. 12.49 Tuning Setting
(at Simple tuning)
Adjustment method
select setting display
Gain display
