13. Frequency
Analysis Function for SCON-CA
Controller
Anti-V
ibration Control
218
[1] Tool buttons
Fig. 13.11 Tool Buttons
Save As
Clicking this button opens the pop-up menu where you can select the type of data to be saved to a file.
Select the applicable data type in this menu and save the selected data to a file under a desired name.
Fig. 13.12 File Save Data Type Selection Pop-up Menu
Only data of the supported data types can be saved.
For example, assume that measurement data is displayed but FFT analysis result is not yet displayed. In
this case, the following conditions apply:
• Save measurement data: Selectable
• Save FFT result data: Not selectable
Fig. 13.13 File Save Data Type Selection (Only “Save Measurement Data” Selectable)
Print
Clicking this button opens the “print setting” window where you can select desired print settings.
[For the print setting, refer to 13.2.4, “Print Setting Window.]
Edit Position Data
Clicking this button launches the position data edit window (online edit window) where you can edit position
data.
This button is selectable only when “Import new controller data” was selected in the “measurement data
selection” window.
