7. Editing Parameters
95
To read a parameter from the file, click File and then select Open to display a “File open” window. Or click File,
point to Send to controller and then select Parameter, to display the “Open” window.
Fig. 7.5 “Open” Window
Select (click) “File name” you want to open, and click Open on the “File Open” window, then the parameter edit
window is displayed.
You can load data from the controller or a file and edit the loaded data.
Fig. 7.7 is a display example when the PCON-CY controller is connected.
You can also print the loaded data.
Edited data can be sent to the controller or saved to a file.
Edited parameters that have been sent to the controller will become effective after the controller power is
reconnected.
To send data to the controller, click Parameter and then select Send to Controller from the main menu, or
click in the toolbar of the parameter edit window.
Select folder in which
parameter data is saved.
Saved file name.
Select controller.
