3. Main W
indow
34
(4) Monitor (Available in the online mode)
[1] [Status]
You can check the various statuses of each axis (axis status, internal flags and I/O ports).
[2] [CTL Alarm List]
Display the CTL alarm list window.
[3] [Velocity/Current]
Display the velocity/current monitor window.
* RCP, RCS and E-Con cannot use this function.
Refer to “Supported Models.”
[4] [Servo Monitor]
Display the servo monitor window.
* This window is available only with SCON-CA, PCON-CA, ERC3 (Software Version V8.03.00.00 or later)
and MSCON controllers.
[Refer to 8.4, “Servo Monitor Window.”]
[5] [Maintenance Information]
Display the maintenance information window.
* This window is available only with SCON-CA, PCON-CA, ERC3 (Software Version V8.03.00.00 or later)
and MSCON controllers.
[Refer to 8.5, “Maintenance Information Window.”]
