11. Smart T
uning Function (V
ersion V8.03.00.00 or Later)
143
Adjustment Record Data Select
This is used when switch over the adjustment record data. Number of selectable adjustment record data
is shown on the right side.
It is able to narrow down the search of the adjustment record data by model select setting. The item with
blank in the model select setting gets excluded from the search conditions.
Example) If set as: Model Code = RCP4-RA5C, Lead = 3mm
Ÿ
The search result is narrowed down from the adjustment record data to those for
RCP4-RA5C with 3mm lead.
Example) If set as: Model Code = RCP4-RA5C, Lead = Blank
Ÿ
The search result is narrowed down from the adjustment record data to those for
RCP4-RA5C no matter the lead length.
Click on << or >> button and the data on the very end can be selected from the selectable adjustment
record data.
Click < or > button and the cursor moves from 1 record to the next in the selected adjustment record
data.
Putting a number to Edit lying between < and > buttons will let select the indicated adjustment record
data directly.
